Gafchromic XR-RV3皮膚劑量QA免沖洗膠片，Gafchromic XR-RV3膠片
型號：GAFCHROMIC XR-RV3 類別： 質控儀器 品牌：美國Ashlan pdf資料: Gafchromic XR-RV3皮膚劑量QA免沖洗膠片，Gafchromic XR-RV3膠片.pdf
采購熱線：0755-28896837 13632925349
在線咨詢產品
Gafchromic XR-RV3皮膚劑量QA免沖洗膠片，Gafchromic XR-RV3膠片設計用于在透視引導的介入手術中進行表面峰值皮膚劑量測量。用戶友好的FilmQA-XR軟件只需單擊即可提供二維結果。比較器條帶也可用于在一點上快速目測劑量，不需要數字化。能量范圍：30 keV至30 MeV。
Gafchromic XR-RV3膠片規格：14″×17″,25片/盒
Gafchromic XR-RV3 film is designed for surface-peak skin-dose measurement in interventional procedures guided by fluoroscopy. The user-friendly FilmQA-XR software provides 2-D results with a single click. A comparator strip is also available for quick visual estimation of dosage at a point, requiring no digitizing. Energy range: 30 keV to 30 MeV.
Gafchromic XR-RV3膠片規格：14″×17″,25片/盒
| 產品規格 | |||
| 項目編號 | 832486 | ||
| 劑量范圍 | 1 cGy to 15 cGy | ||
| 能量范圍 | ~30 keV至30 MeV | ||
| 空間分辨率 | 5000 dpi | ||
| 外形尺寸 | 14.0“x 17.0”（35.56 x 43.18 mm） | ||
| 組態 | 4層層壓板 | ||
| 基材厚度 | 黃色聚酯 - 97微米 | ||
| 粘合層厚度 | 20微米 | ||
| 活動層厚度 | 17微米 | ||
| 基材厚度 | 白色聚酯 - 97微米 | ||
| 包 | 每包25件 | ||
Gafchromic XR-RV3 film is designed for surface-peak skin-dose measurement in interventional procedures guided by fluoroscopy. The user-friendly FilmQA-XR software provides 2-D results with a single click. A comparator strip is also available for quick visual estimation of dosage at a point, requiring no digitizing. Energy range: 30 keV to 30 MeV.
